進口法蘭電磁閥

這真不是您需要的產品？
品　　牌：
德國萊克品牌

直接提問 | 回首頁搜
出廠價：
1000

主要規格：
0.5-1000

用　　途：

進口法蘭電磁閥進口法蘭高壓電磁閥、德國萊克LIK品牌一、應用范圍 Applications 它廣泛應用在航天、船舶重工、石油化工、工業爐窯、鍋爐、給排水、采暖空調、消防設備、干燥設備食品醫療設備、清洗設備、景觀灌溉、噴泉、水廠等管道系統中. It is widely used in aerospace, shipbuilding Heavy Industry, petrochemical, industrial furnaces, boilers, plumbing, heating and air conditioning, fire-fighting equipment, drying equipment，Food medical equipment, cleaning equipment, landscape irrigation, fountains, water and other piping systems 二、產品特點 Features △不銹鋼活塞式，動作靈敏，壽命長達100萬次；專制線圈不易燒毀；閥安裝方向無限制；適用范圍廣 △Stainless steel piston, movement sensitive, life is 100 million times; autocratic coil easily burned; valve installed on the direction of unrestricted; for a wide range of 三、工作原理 Work △常閉型：線圈通電時，主閥芯靠介質壓差力打開；線圈斷電，閥關閉。 △常開型：線圈通電時，閥關閉；線圈斷電，主閥芯靠介質壓差力打開。 △ Normally closed type: coil power, the main valve to open by medium pressure force; coil power, valve closed △Normally open type: coil power, the valve closed; coil power, pressure forces the main valve opens by media 備注：當出口端壓力大于進口端壓力，介質回反向導通。可安裝止回閥或訂制帶止回功能的閥。 When the exit pressure is greater than the inlet pressure, medium Back to pass against the wizard. Check valve can be installed or ordered withnon-return valve function 四、法蘭型規格尺寸 Flange type Size 五、主要技術參數 Main technical parameters △產品型號 Product Type: △動作方式：直動式、分步直動式、先導式。 △Action by: direct-acting type, direct-action step, Pilot. △閥體材質：鑄鋼體、不銹鋼。（鑄鋼體不能用在腐蝕流體上） △Body material: cast steel body, stainless steel. (Steel body can not be used in corrosive fluid on) △控制方式：常開、常閉、自保式。 △Control mode: Normally open, NC, self-protection type. △適用介質：水、氣、油、蒸汽、燃氣、腐蝕流體 △ Suitable medium: water, gas, oil, steam, gas, corrosive fluid △工作溫度 Operating temperature: -200℃～0℃；-60℃～+100℃；-20℃～+80℃；-20℃～+150℃；0℃～+200℃；0℃～+350℃. △防護性能：防水、防爆（Exd IICT5）、防腐。 △ Protection performance: waterproof, explosion-proof (Exd IICT5), anti-corrosion △工作電壓 Operating Voltage： DC12V、DC24V、DC36V、DC110V、DC127V、DC220V;AC36V、AC110V、AC220V、AC380V △接線方式：接線座式、引線式、插座式。 △Wiring: Wiring Block type , lead type , socket △附加功能：帶信號反饋、帶手動控制、帶止回功能 △Additional features: with signal feedback, with manual control, with a return function 進口超高壓電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=317 · 進口二位二通高壓電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=318 · 進口超高溫電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=319 · 進口高溫電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=320 · 進口超低溫電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=322 · 進口液氮低溫電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=323 · 進口氮氣電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=324 · 進口不銹鋼高壓電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=325 · 進口電動法蘭球閥 http://www.dghwvalve.com/pro_show.asp?ID=332 · 進口高壓電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=335 · 進口電動套筒調節閥 http://www.dghwvalve.com/pro_show.asp?ID=444 · 進口蒸汽電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=336 · 進口不銹鋼電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=337 · 進口防爆電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=338 · 進口帶信號反饋電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=339 · 進口帶手動功能電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=340 · 進口燃氣緊急切斷閥 http://www.dghwvalve.com/pro_show.asp?ID=341 · 進口燃氣緊急切斷電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=342 · 進口燃氣電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=343 · 進口潛水電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=344 · 進口高壓防爆電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=345 · 進口真空電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=346 · 進口法蘭電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=347 · 進口高壓內螺紋電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=348 · 進口直動式電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=349 · 進口先導式電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=350 · 進口水用電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=351 · 進口內螺紋電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=352 · 進口法蘭高壓電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=353 · 進口零壓啟動電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=354 · 進口防水電磁閥 http://www.dghwvalve.com/pro_show.asp?ID=355
